冷却灭火

-500
消防员在受控环境中用水喉灭火,化学工程应用。.

(图片仅供参考)

A primary method of fire extinguishment involves removing the ‘heat’ component of the 火三角. This is most commonly achieved by applying a substance that absorbs a large amount of heat, such as water (despite water also have other effects in the fire triangle -refer to dedicated post-). Water’s high specific heat and 潜热 of vaporization make it highly effective at cooling a fire below its self-sustaining temperature.

Extinguishment by cooling is a fundamental firefighting tactic that directly targets the ‘heat’ side of the 火三角. The goal is to reduce the temperature of the burning material to a point where it no longer produces sufficient flammable vapor to sustain combustion. This point is known as the fire point. Water is the most common cooling agent due to its unique thermal properties. It has a high specific heat capacity, meaning it can absorb a significant amount of thermal energy before its own temperature rises substantially. More importantly, it has a very high latent heat of vaporization. When liquid water turns into steam at 100°C, it absorbs a massive amount of energy from the fire without any change in temperature. This phase change is extremely efficient at drawing heat away from the fuel. The resulting steam also helps to displace oxygen, contributing to extinguishment by smothering. However, using water is not always appropriate. It can be ineffective or dangerous on grease fires (it can spread the burning grease) and electrical fires (due to conductivity), and it can react violently with certain metal fires.

UNESCO Nomenclature: 3305
- 化学工程

类型

物理过程

中断

递增

用法

广泛使用

前体

  • 观察水对火的影响
  • 了解热量和温度
  • development of thermodynamics, specifically concepts of specific heat and 潜热
  • 发明了用于输水的泵和软管

应用程序

  • 消防栓和水管
  • 建筑物喷水灭火系统
  • 为野火提供洒水飞机
  • 个人水灭火器
  • 蒸汽惰化系统

专利:

NA

潜在创新理念

  • 超声波 water mist systems with smaller droplets for more efficient heat absorption
  • 灭火凝胶可粘附在表面并提供长时间的冷却
  • 无人机可高精度投放目标冷却剂
  • 用于专业工业灭火的相变材料浆液
  • self-activating cooling systems embedded in 锂离子电池 packs
  • 声波灭火器利用声波产生压力变化并冷却火焰前沿
  • 用于敏感电子环境的低温液氮灭火器
  • 智能喷水灭火系统可根据火灾强度调节水流量和水滴大小
  • 可生物降解的冷却泡沫,也可作为蒸汽屏障
  • 用于高科技设备局部防火的热电冷却板
相关内容: 冷却、灭火、水、汽化热、比热、灭火、自动喷水灭火系统、消防、散热、火灾三角区。.
